AUM 07.TVB - washbasin, small sink, wall mounted, with thermostatic valve - 6V (4x1,5)
AUM 07 is a sensor-controlled stainless steel washbasin intended mainly for assembling in slaughterhouse lines or eventually onto a wall with a limited space. The washbasin is equipped with sensor-controlled outlet arm. Water turns on automatically when the user's hands are placed within the sensor's range and turns off when they have been removed. Water stops running with a certain time delay after the hands have been removed from the scanning zone. The washbasin is equipped with a mechanism against excess pressure of hot and cold water.
AUM 07 is manufactured from the stainless steel AISI 304. Other materials (e.g. AISI 316) possible on order. For cleaning we recomnned WÜRTH detergents ? material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).
Complete delivery
- sink with sheathing
- outflow arm
- photocell head
- electronics
- electromagnetic valve (AUM 07.2, .TV ? 2 pcs)
- corner valve with filter (AUM 07.2)
- spherical valve (AUM 07.TV)
- thermostatic valve (AUM 07.TV)
- through-flow water heater (AUM 07.E)
- source of power supply ZAC E ? 12 V, 50 Hz (AUM 07.E)
- waste siphon
- connecting hoses
- small assembly materials
Requirements for setting up the construction
- Set-up water inlet as per picture
- Set-up outlet d = 40 mm
- Set-up cable for power supply ? 12 V, 50 Hz from source of power supply ZAC (does not apply to AUM 07.E)
- Set-up cable CYKY 3C x 1,5 ? 2,5 (for AUM 07.E)
Download information about the product
Basic technical information
| Radius of sensor | self-adjusting |
| Water inlet | G 1/2? |
| Outlet | d = 40 mm |
| Inner dimension of the washbasin | 300 x 240 x 100 mm |
| Adjustable time of water flow | 0 ? 4 sec. (adjusted to 1 sec.) |
| AUM 07.1, .2, .TV | |
| Water pressure | 0,2 ? 0,6 MPa |
| Power supply | 230 V, 50 Hz |
| Power requirement | 3 500 W |
| Source of power supply | ZAC 1/20 (max. 3 x AUM 07) |
| ZAC 1/50 (max. 8 x AUM 07) | |
| Electricity protection | IP 54 |
| Weight | 9,5 kg |
| AUM 07.E | |
| Recommended pressure | 0,3 MPa (without variances and air bubbles) |
Figures
| A - | cold water mixed water inner pipe G1/2" | E - | zone of scaning | |
| B - | hot water inner pipe G1/2" | T - | thermostatic valve (AUM 07.TV) | |
| C - | electricity supply | * - | made to order | |
| D - | outlet |
